Fixed Long Range Uhf Rfid Reader IP65 Industrial Outdoor Support Global Frequency

Product Categories
Shenzhen Rakinda Technology Development Co., Ltd.
Contact Now

Fixed Long Range Uhf Rfid Reader IP65 Industrial Outdoor Support Global Frequency

Brand Name : SCANMAX

Model Number : SM-RF850

Certification : GB/T7722-2005

Place of Origin : China

MOQ : 1PCS

Price : Negotiation

Payment Terms : Western Union, T/T, L/C, D/A, D/P, MoneyGram

Supply Ability : 200PCS/Week

Delivery Time : Within 5 working days after receiving the balance

Packaging Details : Normal craft paper and foam

Frequency : 840 to 960MHz (support global frequency)

Supported protocols : EPC global UHF class 1Gen2, ISO/IEC18000-63

Pola rization : Circular

Non-condensing gain : -7 dBi integrated antenna

Operation mode : single/dense reader mode

RF output power configurable : -9 to -30 dBm, software

Contact Now

The new SM-RF850 Fixed RFID Reader introduces advanced RFID radio technology for faster, more accurate read rates and more consistent performance even in challenging environments. It is based on Linux for ease of programming and communication. With multiple connectivity options it is ideally suited for vehicle, personnel and assettracking applications.

Long Distance Fixed RFID Reader Key Features

• Low profile -7dBi integrated antenna reader
• Circular Polarization
• Second RF port for additional antenna
• TCP/IP and RS-232 Communication
• Onboard GPIO or Wiegand Output
• API: JAVA, .NET, C++
• Protection Level: IP65

Fixed Long Range Uhf Rfid Reader IP65 Industrial Outdoor Support Global Frequency

Fixed Long Range Uhf Rfid Reader IP65 Industrial Outdoor Support Global Frequency

Long Distance Fixed RFID Reader Parameters

Physical parameters
Dimensions 291 x 291 x 86mm (11.4 x 11.4 x 3.4in)
Weight 2KG (4.4Lbs)
Case material Aluminum Alloy / ASA
Quantity 5000pcs/roll, 4 rolls/carton 5000pcs/roll, 8 rolls/carton 5000pcs/roll, 8 rolls/carton
Environment
Operating temperature -40℃ to 70 ℃ (-4℉ to 158 ℉)
Storage temperature -40℃ to 70 ℃ (-4℉ to 158 ℉)
Humidity range 5% to 95%, non-condensing
IR rating IP65
Power source
Adapter (not included) AC input 100v-240v 1.5A, 50-60Hz; DC output 24V ± 5%/2.5A
Power consumption App ox. 12W
Power over Ethernet IEEE 802.3at
Communication/Network
Communication interface RS-232
10/100 Ethernet network protocol TCP/IP, DHCP
UHF RFID
Supported protocols EPC global UHF class 1Gen2, ISO/IEC18000-63
Frequency 840 to 960MHz (support global frequency)
Performance parameter
GPIO 2 inputs, optically isolated 3 relay control outputs or 2 wiegand outputs with 26/34/66 type
Operation mode single/dense reader mode
RF output power configurable -9 to -30 dBm, software
Antenna
Non-condensing gain -7 dBi integrated antenna
Pola rization Circular
Antenna ports 1xRP - TNC (Male)
