Multi Tag Handheld RFID Reader Long Range Scanner SDK For Easy Integration

Shenzhen Rakinda Technology Development Co., Ltd.
Contact Now

Multi Tag Handheld RFID Reader Long Range Scanner SDK For Easy Integration

Brand Name : SCANMAX

Model Number : SMB02H

Certification : GB/T7722-2005

Place of Origin : China

MOQ : 1PCS

Price : Negotiation

Payment Terms : Western Union, T/T, L/C, D/A, D/P, MoneyGram

Supply Ability : 200PCS/Week

Delivery Time : Within 5 working days after receiving the balance

Packaging Details : Normal craft paper and foam

Antenna : 3dbi circularly polarized antenna

Working frequency : 860Mhz – 960Mhz

Air interface protocol : EPCglobal UHF Class 1 Gen 2/ISO 18000-6C ISO 18000-6B

Read tag peak speed : > 200 sheets / sec

Reading distance : 3~15m (Related to factors such as label size)

Precision : ≥3mil

Image sensor : 752×480 CMOS

Focus : Laser 650nm

Contact Now

Bring a new level of comfort, task speed, ease of use, and accuracy to RFID applications with the SMB02H Integrated UHF RFID Handheld. You get superior RFID read performance and receiver sensitivity for fast, accurate capture of challenging RFID tags, and the ability to capture 1D and 2D barcodes.

Handheld RFID Reader Key Features

1. Bluetooth Communication

The software adapts quickly, the mobile phone does not need to make any changes (providing communication interface, SDK and source code), which greatly shortens the project landing time.

2. Long life cycle, low cost of iteration

After the mobile phone is upgraded or replaced with a new battery, this is the latest PDA: not only can the low-cost sharing of the mobile phone/table change performance, but also the cost of purchasing. Dynamic data collection function.

3. Good heat dissipation and durability

Metal body heat dissipation is good, long life is not dead, and it is durable and durable.

4. Tilt design with handle

The handle has a good grip, easy operation and good reading angle.

Multi Tag Handheld RFID Reader Long Range Scanner SDK For Easy Integration

Multi Tag Handheld RFID Reader Long Range Scanner SDK For Easy Integration

Handheld RFID Reader Parameters

Charge and discharge function parameter Charging Voltage 5.0±0.25V DC
Output Voltage 5.0±0.25V DC
Nominal Capacity 6000mAh
Standard charging currency <2A
Standard charing Method CV (constant voltage 5.0V) charging
Charging Time ≤ 4 hours (1 charge cycle time for BACKPOWER internal battery)
MAX charging currency <2A
MAX discharging currency <2A
Communication Interface Bluetooth
UHF Function Working frequency 860Mhz – 960Mhz
Air interface protocol EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C ISO 18000-6B
Output Power 0~33dBm
Antenna 3dbi circularly polarized antenna
Reading distance 3~15m(Related to factors such as label size)
Read tag peak speed > 200 sheets / sec
1D/2D functions Image sensor 752×480 CMOS
Light CCD LED 625±10nm
Focus Laser 650nm
Symbologies 2D PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140)
1D Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, Code 11, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Industrial 2 of 5,Standard 2 of 5, Plessey, MSI-Plessey ,etc
Precision ≥3mil
(Options)Typical reading depth of field EAN-13 60mm~290mm (13mil)
PDF417 55mm~135mm (6.7mil)
Code39 55mm~165mm (5mil)
Data Matrix 55mm~130mm (10mil)
QR Code 45mm~175mm (15mil)
Symbol contrast ≥20%Reflection difference
Barcode sensitivity Rotate 360°, tilt ±55°, deflection ±55°
Field of view 36° horizontal and 23° vertical
Infrared emission tube center wavelength 940nm
IrDA Power meter reading function (optional) Infrared receiver tube 38kHz Modulation frequency
Reading distance >3m
Transmission baud rate 1200bps
Data communication bias 35°
Working currency ≤30mA
Flashlight Powerful torch 1W Strong light flashlight for use in dark environments.
Environment Operating temperature 0℃~45℃
Storage temperature -10℃~ +45℃
Working humidity 5% - 95% ( No condensation )
Standard Type C USB charging cable
Certificate
Electronic manual
Options 5V/2A & 5V/1A two-way separate output high-quality car charger (the indoor mobile phone charger can be used to charge the mobile phone and the back clip at the same time, the outdoor car can be charged, the car charger can also charge the tablet.)
Back clip lanyard
AC charger
Phillips screwdriver
Waist bag

Multi Tag Handheld RFID Reader Long Range Scanner SDK For Easy Integration
