RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code

Name: RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code
Brand: Rakinda
Price: 1 USD

RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code Manufactures

Brand Name : Rakinda

Model Number : RD11P

Certification : CE, RoHS,FCC

Place of Origin : China

MOQ : 1PCS

Price : Negotiation

Payment Terms : Western Union, T/T, L/C, D/A, D/P, MoneyGram

Supply Ability : 200PCS/Week

Delivery Time : Within 5 working days after receiving the balance

Packaging Details : Normal craft paper and foam

Product Name : mini size QR code scanner

Warranty : 1 years

Application : PDA,POS machine handheld devices

Type : Plug and play

Contact Now

RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code

Features:

Armed with Rakinda ’s six-generation of technology, the scan engine can swiftly and effortlessly decode even poor quality barcodes.

1) High Performance & Ultra-Low Power Consumption:The engine can read 1D and 2D barcodes with a power consumption only one third that of a traditional engine.

2) All-in-One Design:Seamless integration of image sensor and decoder board makes the scan engine small, lightweight and easy to fit into even the most space-constrained equipment. Easy for integration.

3) All-Round Scanning Capability: It can read barcodes on virtually any medium - paper, plastic cards,mobile phones and LCD display.

Application Scenarios (as an accessory)

Self-service cabinets used in e-commerce, express delivery services and smart homes; ATMs; kiosks; queue machines; lottery machines; certificate makers.

RD11P 2D Scan Engine

Specification
Optical System		1280 pixels(H)x 800 pixels(V)
Illumination Element		Aiming: 617nm LED; Illumination 5600K White LED
Depth of Field		30 mm - 320 mm @UPCA -13 mil 100 %,PCS 90%
Scan Angle		46° (H) x 29° (V)
Min. Bar Width		0.1mm(4mil)@Code 39, PCS=90%
Scan Mode		Trigger mode, Auto-sensing, Continuous scan, Pulse mode
Print Contrast		> 30%(UPC/EAN 100% , PCS 90%)
System Interface		USB 1.1 (HID Keyboard,Virtual COM Port) RS-232 (9.6~115.2Kbps)
Depth of Field
PHYSICAL CHARACTERISTICS
Dimensions	28.2mm x 20.5mm x 11.8mm
Weight	About 5g
Input Voltage	DC 3.3V±5%
Operating Current	130 mA ±5%(Typical), 300 mA ±5%(Max.)
REGULATORY
EMC	CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI
ENVIRONMENT & SAFETY
Operating Temperature	-20℃~50℃
Humidity	5%~95% (non-condensing)
Storage Temperature	-40℃~+70℃
Light Level	0~100,000Lux(fluorescence )
DECODING CAPABILITY
UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS 14,RSS Limited, RSS Expanded PDF417 MicroPDF417 Data Matrix QR Code Micro QR Code Aztec Code Maxi Code Reads barcode reliably of cell phone screens

RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code

Product Tags:

intelligent door lock

keyless entry door lock

RD11P mini size QR code scanner 1D 2D barcode reader engine oem module PDF417 datamatrix code Images
